SMD/GOB Indoor Small Pitch · 16:9 Cabinet · ≥8000:1
SMD/GOB Indoor Small Pitch · 16:9 Cabinet · ≥8000:1
M-PRO Series is a professional SMD/GOB indoor small pitch LED display. Perfect 16:9 aspect ratio die-cast aluminum cabinet with SMD/GOB selectable technology. Common cathode design for energy efficiency. Ideal for conference rooms, control centers, classrooms, and exhibition halls.
Inquiry / 询价| Pixel Pitch | P1.25 / P1.56 / P1.87 (common cathode) |
|---|---|
| Pixel Structure | 1R1G1B SMD/GOB (selectable) |
| Pixel Density | 640,000 / 409,600 / 284,444 dots/㎡ |
| Module Size (W×H) | 150×337.5mm |
| Backshell | No Backshell |
| Cabinet Material | Die-Casting Aluminum |
| Aspect Ratio | 16:9 (Perfect) |
| Scanning Method | 1/60 / 1/30 / 1/30 |
| Refresh Rate | ≥3840Hz |
| Brightness | 500-600 cd/㎡ |
| Contrast Ratio | ≥8000:1 |
| Protection | Water Proof & Dust Proof |
Perfect 16:9 aspect ratio cabinet — direct replacement for traditional LCD panels and projectors in meeting rooms and classrooms.
GOB (Glue-on-Board) optional technology — adds extra protection layer over SMD LEDs, waterproof and dustproof for educational and commercial environments.
Common cathode design with 3840Hz refresh — energy-efficient operation with flicker-free viewing comfort for extended conference sessions.
