SMD Outdoor Fixed · Front Maintenance · High Brightness
SMD Outdoor Fixed · Front Maintenance · High Brightness
D-PRO Series is a professional outdoor fixed SMD LED display with front maintenance design. Available in P5-P10 with both common cathode and common anode options. Die-cast aluminum module (480×320mm) delivers up to 10,000cd/㎡. Ideal for commercial storefronts, museums, and gas stations.
Inquiry / 询价| Pixel Pitch | P5 / P5.7 / P6.67 / P8 / P10 |
|---|---|
| Pixel Structure | 1R1G1B (Common Cathode / Common Anode) |
| Pixel Density | 40,000 / 30,772 / 22,477 / 15,625 / 10,000 dots/㎡ |
| Module Size (W×H) | 480×320mm |
| Backshell | Die Casting Aluminum |
| Supply Voltage | DC 3.2/4.2V |
| Max Current | 9A+13A |
| Brightness | Up to 10,000 cd/㎡ |
Purpose-built for commercial outdoor signage — high brightness up to 10,000cd/㎡ ensures visibility under direct sunlight at storefronts and roadsides.
Convenient front maintenance design — no need for rear access, significantly reducing service time and cost for permanent outdoor installations.
Common cathode option available for superior energy efficiency — lower operating temperature extends LED lifespan for 24/7 outdoor operation.
